KingSpec YANSEN 44Pin 2.5" SATA SSD

The KingSpec YANSEN 44Pin 2.5" SATA SSD delivers lightning fast performance with up to 107MB/s sustained read and 60MB/s sustained write speeds. Its MLC-NAND Flash and dynamic/static wear-leveling ensure reliable and enduring data storage. And with a write endurance of 80 years, it's built to last. Upgrade to the KingSpec SATA 2.5 MLC and experience superior storage like never before!

Brand Information:

• Brand Name: KingSpec
• Model: SATA 2.5 MLC

General Information:

• Form Factor: 2.5
• Interface: PATA

Performance:

• Capacity: 8GB | 16GB | 32GB | 64GB | 128GB
• Sustained Read: 90MB/S | 100MB/S | 105MB/S | 108MB/S | 107MB/S
• Sustained Write: 26MB/S | 30MB/S | 60MB/S | 59MB/S | 60MB/S
• Random IOPS:
• 4KB Random Read IOPS:
• 4KB Random Write IOPS:
• Average Access Time: 0.2ms

Storage Media:

• NAND Flash: MLC-NAND Flash

Power Consumption:

• Input Voltage: 5V+/_5%
• Idle: 0.5W
• Active: 2.0W

Reliability & Endurance:

• Write Endurance: 80 years at 10GBytes write and erase per day at 32GB
• Read Endurance: Unlimited
• Wear-Leveling Algorithm: Dynamic and static wear-leveling
• Data Retention: 10 years at 25ºC
• MTBF: 1,000,000 hours
• ECC: Supports BCH ECC 8bits or 15bits in 512 bytes
• Bad Block Management: Auto Bad Block Management in the system

Environment:

• Operating Temperature: 0~70ºC
• Non-operating Temperature: -40~85ºC
• Shock: 2,000G (at 0.3ms half sine wave)
• Vibration: 20G (40-2000HZ)
• Ambient Humidity: 5-95%

Physical Dimensions & Weight:

• Height(mm): 9.5+/_0.25
• Width(mm): 69.8+/_0.25
• Length(mm): 100.2+/_0.25
• Weight(g): 70±5

Testing Software:

• HD Bench 3.4.0.3
• IOMeter 2006.07.27
